Redesigned from the ground up, the Revo X spinning reel has been engineered to deliver unmatched performance and durability. It combines a Zenon inspired A-SYM body design to minimise the body size and optimise weight and balance with the AM-G fully machined gear systems for the ultimate in smoothness and cranking power. Casting performance is maximised by the V-Rotor design and Rocket line management™ system that allows anglers to fish mono, braid, and even difficult-to-manage fluorocarbon.
- 6 stainless steel HPCR™ bearings + 1 roller bearing
- Asymmetrical body design
- V-Rotor design
- V-Spool design
- Rocket line management™ system
- Rocket spool lip design™
- Machined aluminium braid ready spool
- Carbon Matrix™ drag system
- Aluminium handle with co-moulded soft touch knobs
- AMG-2 gearing system
- Stainless steel main shaft and components
- Slow Oscillation
SPECIFICATIONS
| MODEL | SIZE | BRAID CAPACITY M/MM | GEAR RATIO | MAX DRAG | DRAG TYPE | DRAG MATERIAL | BEARING COUNT | REEL SPOOL MATERIAL | WEIGHT |
|---|---|---|---|---|---|---|---|---|---|
| REVO3 X SP10 | 10 | 135/0.12 | 6.2:1 | 11lb | 5.2kg | Front Drag | Carbon Fibre | 7 | Aluminium | 201g |
| REVO3 X SP20 | 20 | 155/0.15 | 6.2:1 | 11lb | 5.2kg | Front Drag | Carbon Fibre | 7 | Aluminium | 210g |
| REVO3 X SP30 | 30 | 160/0.17 | 6.2:1 | 11lb | 5.2kg | Front Drag | Carbon Fibre | 7 | Aluminium | 221g |
| REVO3 X SP40 | 40 | 170/0.20 | 6.2:1 | 11lb | 5.2kg | Front Drag | Carbon Fibre | 7 | Aluminium | 227g |
